Vari Lite VL4000 - Left Strobe Assembly

VARI❋LITE - VL4000 BEAMWASH LUMINAIRE SERVICE MANUAL
106 02.9704.6010 0
Left Strobe Assembly
21.9704.0431 Rev. G
Refer to Figure 3-52
No. Item Qty. UM. Description
1 10.9704.0420 1 EA MOUNT PLATE, STROBE
2 22.9704.0453 1 EA ASSY, STROBE BLADE
3 44.9687.1204 1 EA MOTOR, SIZE 17, SHAFT 0.455"
4 53.6682.0002 2 EA SCREW, 4-40 X 1/4" PPZ SEMS
5 55.6738.0005 0.625 IN TUBING, SILICONE RUBBER, 4 MM ID, 8 MM OD, SOFT RED
6 53.6559.0001 1 EA SCREW, 4-40 X 1/4" PFZ
