Vari Lite VL4000 - Pan Bearing; Pulley Assembly

VARI❋LITE - VL4000 BEAMWASH LUMINAIRE SERVICE MANUAL
132 02.9704.6010 0
Pan Bearing / Pulley Assembly
21.9704.0840 Rev. F
Refer to Figure 3-60
No. Item Qty. UM. Description
1 10.9704.0863 2 EA BRACKET SUPPORT
2 10.9704.4891 1 EA BRACKET, STABILIZER, PAN
3 10.9704.1809 1 EA EXTENSION, PAN TUBE
4 53.6536.0001 2 EA SCREW, 4-40 X 1/2" PFZ
5 53.6609.0001 1 EA SCREW, 6-32 X 3/8" PFZ
6 53.6558.0009 1 EA SCREW, 6-32 X 3/8" LG PPZ SEMS
7 53.6575.0010 5 EA SCREW, 8-32 X 1/2" PPZ SEMS
8 53.6545.0007 4 EA SCREW, 8-32 X 3/8" PFB
9 53.6627.0001 5 EA SCREW, 10-32 X 5/8" PPB
10 55.6568.0075 1 EA SPRING, EXTSN, 1/2" FL, X 1/8" OD
11 10.9704.4890 1 EA STABILIZER, PAN, 1.950" SHAFT
12 10.9704.1808 2 EA TIMING PULLEY, 150 TOOTH
13 22.9704.4850 1 EA VL4000 PAN TUBE ASSY
14 17.9704.0910 1 EA VL4000 PAN TUBE ENCODER
