ENCLOSURE ASSEMBLY : PAN BEARING / PULLEY ASSEMBLY
02.9704.6010 0 133
3
Pan Bearing / Pulley Assembly (continued)
Figure 3-67: Pan Bearing / Pulley Assembly
4 (x2)*
*APPLY LOCTITE 242 TO THE THREADS OF
ALL SCREWS PRIOR TO INSTALLATION.
6*
14
1
13
8 (x4)*
10
1
5*
11
2
9 (x5)*
7 (x5)*
3
12 (x2)
