CABLE ASSEMBLIES : LVS CHASSIS GROUND CABLE ASSEMBLY
02.9704.6010 0 139
3
Note: Cables are only available as complete assemblies. The information contained in this
section is for reference only.
Cable Assemblies
LVS Chassis Ground Cable Assembly
25.9687.0025 Rev. A
Refer to Figure 3-71
Figure 3-71: VL4000 Pan / Tilt Cable Assembly
