Enclosure Components
The following illustration shows the major sub-assemblies which are located in the luminaire
enclosure assembly. (Yoke and head assemblies not shown for clarity.)
Input Panel Assembly
Contains DMX Input, PCB
AC Input, and Menu Display
Enclosure Top Covers
Pan Motor Assembly
Fan Assembly
Bracket Mounting Buttons
Enclosure Handle
PFC Supply
Lamp Driver
Enclosure Handle
Pan Tube Assembly
36 VDC / Low-Voltage
Power Supply
