TOP ASSEMBLY : VL4000 BEAMWASH LUMINAIRE
02.9704.6010 0 37
3
VL4000 BeamWash Luminaire
20.9704.0002 Rev. A
Refer to Figure 3-8
No. Item Qty. UM. Description
1 04.9704.6001 1 EA VL4000 BEAMWASH PRODUCT ID LABEL
2 04.9704.6145 1 EA LABEL VL4000 BEAMWASH, WARNING AND COMPLIANCE
3 10.9704.6641 2 EA FILTER, FOAM, HEAD INLET
4 10.9704.6672 2 EA FRONT SIDE RAIL COVER
5 10.9704.6673 2 EA REAR SIDE RAIL COVER
6 10.9704.6674 1 EA COVER, NOSE, VL4000 BEAMWASH
7 21.9704.6010 1 EA ASSY, GENERIC LUMINAIRE, VL4000
8 21.9704.6200 1 EA ASSY, GOBO/ANIMATION
9 21.9704.6671 1 EA ASSY, BACK COVER
10 21.9704.7400 1 EA ASSY, COLOR MODULE
11 22.9704.6670 2 EA ASSY, HEAD COVER, VL4000 BEAMWASH
12 22.9704.6732 2 EA ASSY, YOKE ARM COVER, VL4000 BEAMWASH
13 28.9704.0002 1 EA INCLUDED ITEM KIT, VL4000 BEAMWASH (NOT SHOWN)
14 53.6543.0001 16 EA SCREW, 6-32 X 3/8" PPB
15 53.6558.0010 4 EA SCRE, 6-32 X 1/4" LZ PPZ SEMS-EXT WSHR
16 53.6614.0001 2 EA SCREW, 6-32 X 5/8" PPB
