Included Items Kit, VL4000 BeamWash (continued)
Figure 3-7: Included Items Kit, VL4000 BeamWash Luminaire
Note: * = Do not handle lamp with bare hands. When handling, it is best to wear clean cotton gloves
in order to keep the lamp’s glass as dirt and grease free as possible.
VL4000 BeamWash Luminaire
QuickStart Guide
5
4
6
(x2)1
22*
3
2
8
Stacked Ovals
9
Chopped
10
Sliced
11
Night Sky
12
Blades
13 14 15 16 17
Psyclone Circle of Holes Circle of Eights Punch Card Vertical Bars
18 19 20 21
Lattice Wavy Triangle Dot Buffet Quadcone, Red
