Vari Lite VL4000 - VL4000 Beamwash Optics Assembly

HEAD ASSEMBLY : VL4000 BEAMWASH OPTICS ASSEMBLY
02.9704.6010 0 49
3
VL4000 BeamWash Optics Assembly
21.9704.6150 Rev. D
Refer to Figure 3-15 and Figure 3-16
No. Item Qty. UM. Description
1 10.9704.0240 1 EA SPACER, 0.197" ID, 0.250" OD, 0.032" THK
2 10.9704.6170 1 EA LIGHT BAFFLE, LENS GROUP 1
3 10.9704.6174 1 EA SHIELD, OPTICS MOTORS
4 10.9704.6180 2 EA RAIL MOUNT, VL4000 BEAMWASH OPTICS
5 10.9704.6181 1 EA MOUNT, LENS GROUP 3
6 10.9704.6182 1 EA REAR ASSY MOUNT SUPPORT
7 10.9704.6186 1 EA MOUNT, LENS GROUP 1
8 10.9704.6188 2 EA CLAMP, BELT DRIVE
9 10.9704.6189 1 EA MOUNT, LENS GROUP 2
10 10.9704.6325 1 EA ARM STOP MOUNT
11 21.9704.6185 1 EA ASSY, EDGE LENS MOTOR
12 21.9704.6195 1 EA ASSY, ZOOM LENS MOTOR
13 21.9704.6310 1 EA ASSY, LENTICULAR W/ MOTORS
14 21.9704.6330 1 EA ASSY, PRISM
15 21.9704.6355 1 EA ASSY, WASH
16 21.9704.6360 1 EA ASSY, WASH ARM MOTOR
17 22.9704.0264 1 EA SHAFT ASSY, GOBO WHEEL 2
18 22.9704.6113 1 EA LINEAR RAIL, 268 MM, 1 CARRIAGE
19 22.9704.6114 1 EA LINEAR RAIL, 131 MM, 1 CARRIAGE
20 22.9704.6151 1 EA ASSY, LENS GROUP 1, VL4000 BEAMWASH
21 22.9704.6152 1 EA ASSY, LENS GROUP 2, VL4000 BEAMWASH
22 22.9704.6153 1 EA ASSY, LENS GROUP 3, VL4000 BEAMWASH
23 24.9704.1913 1 EA #BD, 7-WAY MOTOR DRIVER
24 25.9687.0020 2 EA SWITCH, SLOTTED OPTICAL
- 25.9704.6100 1 EA CABLE ASSY, VL4000 BW OPTICS BLKHD CABLE (NOT SHOWN)
25 53.6513.0032 8 EA SCREW, M3 X 0.5 X 10 MM LG PPZ SEMS
26 53.6522.0004 2 EA SCREW, 6-32 X 1/4" SOC HD
27 53.6523.0001 9 EA SCREW, 6-32 X 3/8", SCB
28 53.6545.0003 7 EA SCREW, 8-32 X 3/8" PFZ
29 53.6558.0007 3 EA SCREW, 6-32 X 1/4" PPZ SEMS
30 53.6558.0009 19 EA SCREW, 6-32 X 3/8" PPZ SEMS
