VARI❋LITE - VL4000 BEAMWASH LUMINAIRE SERVICE MANUAL
50 02.9704.6010 0
31 53.6575.0009 8 EA SCREW, 8-32 X 3/8" PPB SEMS
32 53.6599.0001 4 EA SCREW, 4-40 X 3/8" PFZ
33 53.6601.0002 1 EA SCREW, 4-40 X 3/16" PTZ
34 53.6608.0001 12 EA SCREW, 6-32 X 3/8" PFB
35 53.6682.0002 6 EA SCREW, 4-40 X 1/4" PPZ SEMS
36 53.6682.0022 2 EA SCREW, 8-32 X 3/8" PPZ SEMS
37 54.9704.1390 1 EA BELT, TIMING, MXL, 106 GRV, .125" WD, URETH/KEV
38 55.6528.0001 2 EA WASHER, #6 FLAT ZINC
39 55.6538.0001 2 EA WASHER, #6 LOCK INTERNAL TOOTH
40 55.6588.0003 1 EA SPACER, 1/4" ROUND, #6, 0.125" LG
41 55.6738.0005 0.425 IN TUBING, SILICONE, 4 MM ID, 8 MM OD, SOFT RED
42 55.6568.1250 1 EA SPRING, EXTSN, 0.188" OD, 0.022" WD, 1.25" LG, MW
43 04.9704.6105 1 EA DIP SWITCH LABEL, BOARD G
44 10.9704.6171 1 EA LIGHT BAFFLE, LENS GROUP 2
No. Item Qty. UM. Description
