VARI❋LITE - VL4000 BEAMWASH LUMINAIRE SERVICE MANUAL
66 02.9704.6010 0
Back End Assembly
21.9704.6615 Rev. F
Refer to Figure 3-27
No. Item Qty. UM. Description
1 0-100071 3 EA SCREW, PHMS, PH, 10-32 X 1.75", S, BO
2 10.9704.0613 1 EA MOUNT, HOT BOX
3 10.9704.0628 2 EA LIGHT SEAL, FIN ASSY
4 10.9704.1639 1 EA DIVERTER, LAMP TIP
5 10.9704.2614 1 EA PLATE, REAR
6 10.9704.6675 1 EA COUNTERWEIGHT, HEAD, REAR
7 12.9704.0612 1 EA HOT BOX, MACHINED CASTING
8 12.9704.1629 1 EA EXTENSION, BACKCAP, MACHINED CASTING
9 21.9704.0632 1 EA ASSY, LAMP COVER
10 21.9704.6619 1EAASSY, REFLECTOR
11 22.9704.0630 1 EA ASSY, UV GLASS
12 22.9704.0633 1 EA ASSY, MOUNTED LAMP BASE DUCT
13 22.9704.1618 1 EA ASSY, LAMP SOCKET PLATE
14 22.9704.1620 2 EA FIN ASSY, EXHAUST, TRI-BEND
15 22.9704.2636 1 EA DUCT ASSY, LAMP TIP
- 25.9704.7701 1 EA CABLE ASSY, VL4000 BW LAMP SOCKET (NOT SHOWN)
16 53.6522.2500 1 EA SCREW, 6-32 X 1/4" HEX MACH, ZINC
17 53.6558.0003 1 EA SCREW, 6-32 X 3/8" PPZ PLASTIC THD
18 53.6558.0009 18 EA SCREW, 6-32 X 3/8" LG PPZ SEMS
19 53.6559.0001 4 EA SCREW, 4-40 X 1/4" PFZ
20 53.6575.0005 2 EA SCREW, 8-32 X 1-1/2" PPZ
21 53.6575.0010 8 EA SCREW, 8-32 X 1/2" PPZ SEMS
22 53.6596.0002 6 EA SCREW, 4-40 X 5/16" LG PPZ SEMS
23 53.6613.0008 4 EA SCREW, 6-32 X 1/2" PPZ SEMS
24 55.2233.2006 2 EA DZUS RAPIER SNAP-IN RETAINER
25 55.6503.0001 2 EA WASHER, #8 LOCK INT TOOTH
26 55.6546.0004 3 EA WASHER, TEFLON, 0.201" ID X 0.433" OD
27 55.6568.1750 3 EA SPRING, CPRSN, 0.360" OD, 1.75" LG, 0.045" DIA SS
28 55.6636.0003 1 EA WASHER, 0.562" OD X 0.156" ID X 0.046" THK ZINC
29 71.8101.0050 1 EA LAMP SOCKET, BENDER AND WIRTH, PJGX50
