Vari Lite VL4000 - Double Rollers Tilt Motor Assembly

YOKE ASSEMBLY : DOUBLE ROLLERS TILT MOTOR ASSEMBLY
02.9704.6010 0 115
3
Double Rollers Tilt Motor Assembly
21.9704.1765 Rev. B
Refer to Figure 3-57
No. Item Qty. UM. Description
1 04.9704.0701 1 EA DIPSWITCH LABEL, TILT BOARD
2 10.9704.2705 1 EA TILT ENCODER BRACKET MOUNT
3 10.9704.2763 1 EA TILT MOTOR PLATE
4 17.9704.1911 1 EA SENSOR BOARD, TILT
5 21.9704.0764 1 EA ASSY, TILT MOTOR WITH PULLEY
6 21.9704.1760 1 EA TILT BELT TENSION ROLLERS
7 53.2200.0008 3 EA NUT, 8-32 KEPS SS
8 53.6522.0001 2 EA SCREW, 6-32 X 1/4" PPZ
9 53.6546.0001 4 EA SCREW, 8-32 X 5/8" PPB
10 53.6558.0009 2 EA SCREW, 6-32 X 3/8" LG PPZ SEMS
11 53.6567.0001 4 EA SCREW, 4-40 X 1/2" PPZ
12 55.3306.0006 2 EA WASHER, FLAT, 0.375" OD, 0.149" ID, 0.025" THK
13 55.6503.0004 3 EA WASHER, #8 FLAT ZINC
