Vari Lite VL4000 - Side Mount Fan Assembly

VARI❋LITE - VL4000 BEAMWASH LUMINAIRE SERVICE MANUAL
128 02.9704.6010 0
Side Mount Fan Assembly
21.9704.0810 Rev. E
Refer to Figure 3-64
Figure 3-64: Side Mount Fan Assembly
No. Item Qty. UM. Description
1 10.9704.1817 1 EA UPPER ENCLOSURE SIDE WALL FAN MOUNT
2 22.9704.1850 4 EA FAN ASSY WITH RUBBER MOUNTS (NOTE: EACH ASSEMBLY IS 4
RUBBER FAN MOUNTS, 1 FAN, AND 4 NYLON WASHERS)
1
2 (x4)
Part of Item 2
A
i
r
F
l
o
w
Part of Item 2
