VARI❋LITE - VL4000 BEAMWASH LUMINAIRE SERVICE MANUAL
120 02.9704.6010 0
Upper Enclosure Assembly - Part 1
Refer to Figure 3-60
No. Item Qty. UM. Description
1 10.9687.0840 8 EA MOUNTING BUTTON
2 10.9704.0802 4 EA PAN MODULE, THREADED SPACER
3 10.9704.0829 1 EA SAFETY HOOK
4 10.9704.0836 8 EA REINFORCING BRACKET, RIGHT
5 10.9704.0851 1 EA SAFETY HOOK COVER
6 10.9704.1811 1 EA MAIN PLATE, UPPER ENCLOSURE
7 10.9704.1816 1 EA LVS SIDE MOUNT WALL
8 21.9704.0810 1 EA SIDE MOUNT, FAN ASSY
9 21.9704.0825 1 EA UPPER ENCL FRONT PANEL ASSY
10 21.9704.2815 1 EA SIDE MOUNT, FILTER HOLDER
11 22.9704.0830 2 EA HANDLEBAR ASSY
12 53.2200.0006 2 EA NUT, 6-32, KEP SS
13 53.2200.0008 14 EA NUT, 8-32, KEP SS
14 53.5636.0375 16 EA SCREW, 6-32 X 3/8" PFSS-B
15 53.6545.0008 8 EA SCREW, 8-32 X 3/8" PFB, UNDERCUT
16 53.6575.0010 8 EA SCREW, 8-32 X 1/2" PPZ SEMS
17 53.7017.0500 4 EA SCREW, 1/4-20 X 1/2" PFZ
18 53.9704.0075 4 EA SCREW, 1/4-20 X 3/4" PFZ
19 55.6636.0012 4 EA WASHER, 1" OD X 9/32" ID X 0.12" THK, BLACK
