VARI❋LITE - VL4000 BEAMWASH LUMINAIRE SERVICE MANUAL
58 02.9704.6010 0
Lenticular Arm Assembly
21.9704.6315 Rev. B
Refer to Figure 3-21
No. Item Qty. UM. Description
1 10.9704.0238 1 EA ROLLER, TENSION ADJUST, ANIMATION WHEEL
2 10.9704.6311 1 EA ARM, LENTICULAR
3 10.9704.6313 1 EA INDEX PULLEY, LENTICULAR
4 10.9704.6322 1 EA FLAG, LENTICULAR
5 10.9704.6362 1 EA TEFLON BEARING, BORE, LENTICULAR
6 10.9704.6391 2 EA SPACER, TEFLON, LENTICULAR
7 10.9704.6394 1 EA RETAINING RING, PRISM
8 22.9704.6147 1 EA ASSY, LENTICULAR, W/ GLASS
9 53.6559.0001 3 EA SCREW, 4-40 X 1/4" PFZ
10 53.6596.0001 1 EA SCREW, 4-40 X 5/16" PPZ
11 53.6659.0015 3 EA SCREW, 2-56 X 1/4" PFB
12 53.6682.0002 1 EA SCREW, 4-40 X 1/4" PPZ SEMS
13 54.9687.1253 2 EA BEARING, NPB, MR105ZZK13
14 55.2179.0009 1 EA CABLE ANCHOR MOUNT, #4 SCREW
