VARI❋LITE - VL4000 BEAMWASH LUMINAIRE SERVICE MANUAL
60 02.9704.6010 0
Prism Assembly
21.9704.6330 Rev. C
Refer to Figure 3-22
No. Item Qty. UM. Description
1 10.9704.0233 1 EA DRIVE PULLEY, ANIMATION/FIXED COLOR
2 10.9704.0240 2 EA SPACER, 0.197" ID, 0.250" OD, 0.032" THK
3 10.9704.1233 1 EA PULLEY, 16 GRV, 0.125" WD, ANIMATION ARM DRIVE
4 10.9704.6173 1 EA COLLET, MOTOR SHAFT
5 10.9704.6318 2 EA SPACER, 0.125" ID, 0.250" OD, 0.046" THK
6 10.9704.6325 2 EA ARM STOP MOUNT
7 10.9704.6331 1 EA PRISM MOTOR MOUNT
8 10.9704.6341 1 EA SPACER, 0.198" ID, 0.250" OD, 0.157" THK
9 21.9704.6239 1 EA ASSY, TENSION ADJUSTMENT ROLLER, COMPRISED OF:
9a 10.9704.6237 1 EA PLATE, TENSION ADJUST, ANIMATION WHEEL
9b 10.9704.6238 1 EA ROLLER, TENSION ADJUST, ANIMATION WHEEL
9c 53.6601.0002 1 EA SCREW, 4-40 X 3/16" PTZ
10 21.9704.6335 1 EA ASSY, PRISM ARM
11 24.9704.6314 1 EA SENSOR BOARD, INDEX
12 25.9687.0020 1 EA SWITCH, SLOTTED OPTICAL
13 44.9687.1209 1 EA MOTOR, SIZE-17, SHAFT 0.70"
14 44.9704.1213 1 EA MOTOR, SIZE-14, SHAFT 24 MM LG
15 53.6513.0002 4 EA SCREW, M3 X 5 MM PFZ
16 53.6578.0002 2 EA SCREW, 6-32 X 3/16" SET CUP PNT
17 53.6596.0002 3 EA SCREW, 4-40 X 5/16" LG PPZ SEMS
18 53.6682.0002 2 EA SCREW, 4-40 X 1/4" PPZ SEMS
19 54.9704.1390 1 EA BELT, TIMING, MXL, 106 GRV, 0.125" WD, WRETH/KEV
20 54.9704.5333 1 EA BELT, TIMING, MXL, 180 GRV, 0.125" WD, WRETH/KEV
21 55.9704.6305 2 EA STANDOFF, 3/16" HEX, 4-40 X 7/32", F-F
22 55.9704.6332 2 EA STANDOFF, 1/4" RD, 4-40 X 3/8", F-F
23 55.6738.0005 0.85 IN. TUBING, SILICONE, 4MM ID, 8MM, OD, SOFT RED, (0.425")
