VARI❋LITE - VL4000 BEAMWASH LUMINAIRE SERVICE MANUAL
124 02.9704.6010 0
Upper Enclosure Assembly - Part 3
Refer to Figure 3-60
No. Item Qty. UM. Description
1 04.9704.0892 2 EA LABEL, VL4000 BALLAST
2 04.9704.0893 2 EA LABEL, BALLAST DANGER WARNING
3 10.9678.0896 2 EA 4.5-INCH AIR SEAL, UPPER ENCLOSURE
4 10.9704.0874 1 EA INSULATING DUCT, PFC
5 10.9704.1835 2 EA TOP FOAM AIR SEAL
6 10.9704.1857 1 EA INSULATING DUCT, DRIVER SIDE
7 10.9704.2874 2 EA HOLDER, BALLAST WARNING LABEL
8 53.5636.0375 4 EA SCREW, 6-32 X 3/8" PFSS-B
9 53.6558.0007 4 EA SCREW, 6-32 X 1/4" LG PPZ SEMS
10 53.6558.0009 4 EA SCREW, 6-32 X 3/8" LG PPZ SEMS
11 53.6613.0008 16 EA SCREW, 6-32 X 1/2" PPZ SEMS
12 55.2288.0001 4 EA STANDOFF, MF 6-32 X 13/16" LG, 1/4 HEX
13 55.6658.0009 4 EA STANDOFF, 1/4" HEX 6-32 0.75" LG MF
14 55.6658.2500 4 EA STANDOFF, 6-32 X 2.5" LG, 14 HEX ZINC M-F
15 69.9704.0300 1 EA 36VDC, 300W LVS
16 69.9704.1400 1 EA 1200W/1400W LAMP DRIVER
17 69.9704.2450 1 EA 2035W PFC (1400W LAMP)
