Vari Lite VL4000 - Page 141

ENCLOSURE ASSEMBLY : UPPER ENCLOSURE ASSEMBLY - PART 2
02.9704.6010 0 123
3
Upper Enclosure Assembly - Part 2 (continued)
Figure 3-61: Upper Enclosure Assembly Part 2
9 (x4)*
*APPLY LOCTITE 242 TO THREADS PRIOR TO INSTALLATION.
7 (x2)
2
6 (x4)*
4
1 (x4)
3
11 (x2)
5 (x2)
10 (x2)
8 (x4)*
Item 8 is same as item
17 in Figure 3-60.
