CABLE ASSEMBLIES : VL4000 THERMAL CONTROL CABLE ASSEMBLY
02.9704.6010 0 155
3
Note: Cables are only available as complete assemblies. The information contained in this
section is for reference only.
VL4000 Thermal Control Cable Assembly
25.9704.1805 Rev. A
Refer to Figure 3-87
Figure 3-87: VL4000 Thermal Control Cable Assembly
