Vari Lite VL4000 - Upper Enclosure Assembly - Part 2

VARI❋LITE - VL4000 BEAMWASH LUMINAIRE SERVICE MANUAL
122 02.9704.6010 0
Upper Enclosure Assembly - Part 2
Refer to Figure 3-61
No. Item Qty. UM. Description
1 10.9704.0804 4 EA UNTHREADED SPACER
2 21.9704.0840 1 EA PAN BEARING / PULLEY ASSY
3 21.9704.0870 1 EA PAN / FAN DRIVER BOARD
4 21.9704.1820 1 EA PAN ASSY MODULE
5 53.5808.0001 2 EA SCREW, 6-32 X 0.50" LG FLAT PHIL NYLON
6 53.6552.0001 4 EA SCREW, 8-32 X 1/2" PFZ
7 53.6613.0008 2 EA SCREW, 6-32 X 1/2" PPZ SEMS
8 53.7017.0500 4 EA SCREW, 1/4-20 X 1/2" PFZ
9 53.9704.0002 4 EA SCREW, 1/4-20 X 2" ALLEN, FLATHEAD, BLACK
10 55.6538.0002 2 EA WASHER, #6 NYLON, NATURAL
11 55.6879.0001 2 EA WASHER, M4 RETAINING, FLAT, HIQ03R
