Troubleshooting
Error Messages
If a problem occurs during luminaire calibration, at the end of the calibration sequence the Menu
Display will cycle through any applicable error message(s), one at a time until the end of the list is
reached. To review the error messages again, it will be necessary to access them using the Status
function. Also, the VL4000 BeamWash Luminaire stores error messages in a log file within the
luminaire. The log file can be downloaded from the fixture’s USB port as described in "USB Logging"
in the product user’s manual.
To access error messages:
Step 1. Press [ESC].
Step 2. Press [Up] / [Down] arrows until Fixture appears. Press [OK].
Step 3. Press [Up]/ [Down] arrows to access Status. Press [OK]. (Display will now scroll through
any error messages or display OK if no errors).
Table 2-1: Error Messages
Display Meaning
OK No Errors Found - All Sensors Responded Properly
Pan Sensor Pan Sensor (Encoder) Error
Pan Encoder Pan Encoder Error
Tilt Sensor Tilt Sensor (Encoder) Error
Tilt Encoder Tilt Encoder Error
Dimmer Sensor Dimmer Sensor Error
Cyan Sensor Cyan Color Sensor Error
Yellow Sensor Yellow Color Sensor Error
Magenta Sensor Magenta Color Sensor Error
CTO Sensor CTO Sensor Error
Edge Sensor Edge Sensor Error
Zoom Sensor Zoom Sensor Error
Color Whl1 Sensor Color Wheel 1 Sensor Error
Color Whl2 Sensor Color Wheel 2 Sensor Error
Gobo Whl1 Sensor Rotating Gobo Wheel 1 Sensor Error
Gobo 1 Index Sensor Rotating Gobo Wheel 1 Indexing Sensor Error
Gobo Whl2 Sensor Rotating Gobo Wheel 2 Sensor Error
Gobo 2 Index Sensor Rotating Gobo Wheel 2 Indexing Sensor Error
Animation Whl Sensor Animation Wheel Sensor Error
Animation Index Sensor Animation Wheel Indexing Sensor Error
Iris Sensor Iris Mechanism Sensor Error
Prism Sensor Prism Mechanism Sensor Error
Prism Rotate Sensor Prism Rotating Sensor Error
Beam Shape Sensor Beam Shape Sensor Error
Beam Shape Rotate Sensor Beam Shape Rotate Sensor Error
Wash Lens Wash Lens Sensor Error
Strobe Sensor Strobe Sensor Error
