Vari Lite VL4000 - VL4000 Beamwash Yoke Arm Cover Assembly

TOP ASSEMBLY : VL4000 BEAMWASH YOKE ARM COVER ASSEMBLY
02.9704.6010 0 43
3
VL4000 BeamWash Yoke Arm Cover Assembly
22.9704.6732 Rev. A
Refer to Figure 3-11
Figure 3-11: VL4000 BeamWash Yoke Arm Cover Assembly
No. Item Qty. UM. Description
1 10.9704.6732 1 EA COVER, YOKE ARM, BEAMWASH
2 53.2008.0008 4 EA NUT, #8 PUSH
3 53.6521.0001 4 EA SCREW, 8-32 X 1/2 PPB
2 (x4)
1
3 (x4)
