Upper Enclosure Assembly - Part 4
Refer to Figure 3-61
No. Item Qty. UM. Description
1 10.9704.1846 2 EA UPPER ENCLOSURE, SIDE COVER, HI TEMP
2 10.9704.1847 4 EA UPPER ENCLOSURE, SIDE ARM COVER, HI TEMP
3 10.9704.1849 2 EA UPPER ENCLOSURE, FRONT/REAR COVER, HI TEMP
4 21.9704.0850 2 EA UPPER ENCLOSURE COVER
5 53.5636.0375 38 EA SCREW, 6-32 X 3/8" PFSS-B
6 53.6543.0001 2 EA SCREW, 6-32 X 3/8" PPB
- 25.9704.1703 1 EA CABLE ASSY, VL4000 PAN/TILT (NOT SHOWN)
- 25.9704.2704 1 EA CABLE ASSY, VL4000 PAN/PWR DISTRO INPTU W/ SHIELD (NOT
SHOWN)
- 25.9704.1800 1 EA CABLE ASSY, VL4000 PFC POWER INPUT (NOT SHOWN)
- 25.9704.1801 1 EA CABLE ASSY, VL4000 ENCLOSURE PFC OUTPUT W/ SHIELD (NOT
SHOWN)
- 25.9704.0802 1 EA CABLE ASSY, VL4000 DMX (NOT SHOWN)
- 25.9704.0803 1 EA CABLE ASSY, VL4000 BALLAST CONTROL (NOT SHOWN)
- 25.9704.0804 1 EA CABLE ASSY, VL4000 USB INTERFACE (NOT SHOWN)
- 25.9704.1805 1 EA CABLE ASSY, VL4000 THERMAL CNTRL (NOT SHOWN)
- 25.9704.0716 1 EA CABLE ASSY, VL4000 CHASSIS TO YOKE GRND (NOT SHOWN)
