ENCLOSURE ASSEMBLY : UPPER ENCLOSURE ASSEMBLY - PART 4
02.9704.6010 0 127
3
Upper Enclosure Assembly - Part 4 (continued)
Figure 3-63: Upper Enclosure Assembly Part 4
6 (x2)**
4 (x2)
3 (x2)
5 (x38)
1 (x2)
2 (x4)
1
**APPLY LOCTITE 272 PRIOR TO INSTALLING. SCREW IN
UNTIL SCREW HEAD TOUCHES COVER. DO NOT OVER
TIGHTEN.
