ENCLOSURE ASSEMBLY : UPPER ENCLOSURE ASSEMBLY
02.9704.6010 0 119
3
Enclosure Assembly
Upper Enclosure Assembly
21.9704.0800 Rev. Y
Note: For this assembly, there are several breakout drawings for clarity. Each drawing is proceeded
with a bill of materials (BOMs) for the parts of the section of the assembly shown.
Refer to the following BOMs and their associated drawings:
• “Upper Enclosure Assembly - Part 1” on page 120.
• “Upper Enclosure Assembly - Part 2” on page 122.
• “Upper Enclosure Assembly - Part 3” on page 124.
• “Upper Enclosure Assembly - Part 4” on page 126.*
Note: *Cables associated with the Upper Enclosure Assembly are listed in this BOM for reference.
