VARI❋LITE - VL4000 BEAMWASH LUMINAIRE SERVICE MANUAL
76 02.9704.6010 0
Gobo/Animation Module Assembly (continued)
Figure 3-33: Gobo/Animation Module Assembly (Part 4)
*APPLY LOCTITE 242 TO THREADS PRIOR TO INSTALLATION.
43 (x2)
15
40 (x8)*
1
2
14
