VARI❋LITE - VL4000 BEAMWASH LUMINAIRE SERVICE MANUAL
72 02.9704.6010 0
27 44.9704.0217 4 EA MOTOR, SIZE 17, 24 MM SHAFT, SHORT STACK
28 53.6513.0019 6 EA SCREW, M3 X .5 X 5 MM LG, PPB, METRIC
29 53.6513.0008 6 EA SCREW, M3 X .5 X 5 MM LG, PFB, METRIC
30 53.6513.0023 1 EA SCREW, M3 X .5 X 8 MM LG PFZ METRIC
31 53.6513.0024 2 EA SCREW, M3 X .5 X 8 MM LG PPZ METRIC
32 53.6513.0034 1 EA SCREW, M3 X .5 X 10 MM LG, PFZ, METRIC
33 - - EA -
34 53.6558.0009 10 EA SCREW, 6-32 X 3/8" PPZ SEMS
35 53.6559.0001 9 EA SCREW, 4-40 X 1/4" PFZ
36 53.6578.0002 10 EA SCREW, 6-32 X 3/16" SET CUP PNT
37 53.6601.0004 1 EA SCREW, 4-40 X 1/8" PFZ UNDERCUT
38 53.6604.0002 5 EA SCREW, 4-20 X 1/4" THREAD FORMING FOR PLASTICS
39 53.6604.0005 4 EA SCREW, 4-40 X 1/4" PFZ SHEET METAL
40 53.6609.0001 20 EA SCREW, 6-32 X 3/8" PFZ
41 53.6659.0003 2 EA SCREW, 2-56 X 3/8" PPZ
42 53.6682.0002 1 EA SCREW, 4-40 X 1/4" PPZ SEMS
43 53.6685.0500 2 EA SCREW, 6-32 X 1/2" PPB CAPTIVE
44 53.9704.0004 2 EA SCREW, 10-32 X 3/8" HI-LO PPZ THD FORMING
45 54.9698.0002 2 EA BELT, TIMING, MXL, 150 GRV, 0.125" WD, URETH/KEV
46 54.9704.0290 2 EA BELT, TIMING, MXL, 155 GRV, 0.125" WD, URETH/KEV
47 54.9704.1390 1 EA BELT, TIMING, MXL, 102 GRV, 0.125" WD, URETH/KEV
48 - - EA -
49 55.2203.0001 2 EA SCREW, 4-40 X 1/4" PPZ
50 55.9704.0002 4 EA STANDOFF, 1/4" HEX, 6-32. 1.109" LG, FF, ALUM
No. Item Qty. UM. Description
