HEAD ASSEMBLY : COLOR MODULE ASSEMBLY
02.9704.6010 0 95
3
Color Module Assembly (continued)
Figure 3-44: Color Module Assembly (Part 3)
*APPLY LOCTITE 242 TO THREADS PRIOR TO INSTALLATION.
36 (x10)*
Assembly continued from Figure 3-43 on page 94.
16 (x4)
12 (x3)
1 (x5)
41 (x3)
3 (x5)
49 (x10)
48 (x10)
29 (x2)
5 (x4)
CTO
28 (x2)
Yellow
27 (x2)
Cyan
17
21 (x5)
34 (x6)
9 (x6)
23
37 (x4)*
Magenta
A
11
4 (x5)
2 (x5)
47 (x4)*
22 (x4)
26 (x2)
