VARI❋LITE - VL4000 BEAMWASH LUMINAIRE SERVICE MANUAL
92 02.9704.6010 0
- 25.9704.0400 1 EA CABLE ASSY, VL4000 COLOR BLKHED CABLE 1 (NOT SHOWN)
- 25.9704.0401 1 EA CABLE ASSY, VL4000 COLOR BLKHED CABLE 2 (NOT SHOWN)
- 25.9704.0402 1 EA CABLE ASSY, VL4000 COLOR BLKHED CABLE 3 (NOT SHOWN)
- 25.9704.0403 1 EA CABLE ASSY, VL4000 COLOR BLKHED CABLE 4 (NOT SHOWN)
- 25.9704.0711 1 EA CABLE ASSY, VL4000 DATA NETWORK EXTENSION (NOT SHOWN)
- 25.9704.0712 1 EA CABLE ASSY, VL4000 DATA CLR-A TO CLR-B (NOT SHOWN)
32 44.9704.1213 4 EA MOTOR, SIZE 14, SHAFT 24 MM LG
33 44.9704.1214 1 EA MOTOR, SIZE 14, SHAFT 0.50" LG
34 53.2200.0004 5 EA NUT, KEPS, #4-40
35 53.2202.0004 5 EA NUT, 4-40 HEX SS NYLON INSERT
36 53.5558.0125 10 EA SCREW, 8-32 X 0.125" SET SS
37 53.6513.0023 4 EA SCREW, M3 X .5 X 8 MM LG, PFZ, METRIC
38 53.6513.0002 16 EA SCREW, M3 X .5 X 5 MM LG, PFZ, METRIC
39 53.6520.0001 3 EA SCREW, 4-40 X 3/8" PPZ
40 53.6520.0500 8 EA SCREW, 4-40 X 1/2" PPZ SEMS
41 53.6536.0875 3 EA SCREW, 4-40 X 1.00" PFZ
42 53.6558.0001 10 EA SCREW, 6-32 X 3/8" PPZ
43 53.6558.0009 6 EA SCREW, 6-32 X 3/8" PPZ SEMS
44 53.6559.0001 2 EA SCREW, 4-40 X 1/4" PFZ
45 53.6596.0002 4 EA SCREW, 4-40 X 5/16" PPZ SEMS
46 53.6597.0001 4 EA SCREW, 4-40 X 3/16" PPZ
47 53.6609.0001 4 EA SCREW, 6-32 X 3/8" PFZ
48 53.6659.0006 10 EA SCREW, 2-56 X 3/16" PPZ
49 53.6659.0012 10 EA SCREW, 2-56 X 1/8" PPZ
50 53.6685.0500 2 EA SCREW, 6-32 X 1/2" PPB, CAPTIVE
51 55.2203.0001 1 EA SCREW, 4-40 X 1/4" PPZ
52 55.2234.0125 5 EA E-RING, 0.125" ROD DIAM
53 55.6595.0028 2 EA STANDOFF, 4-40, 1/4" HEX, 0.281" LG, F/F
54 55.6669.0022 1 EA STANDOFF, 4-40, 1/4" HEX, 0.500" LG, M-F
55 55.6818.0002 2 EA CABLE TIE, KURLY-LOC
56 55.7005.0005 10 EA O-RING, SILICONE, DASH# 005, 7/64" ID, 15/64" OD
57 04.9704.0401 1 EA DIPSWITCH LABEL, COLOR BOARDS
58 21.9704.0432 1 EA ASSY, STROBE, RIGHT
No. Item Qty. UM. Description
