HEAD ASSEMBLY : COLOR MODULE ASSEMBLY
02.9704.6010 0 93
3
Color Module Assembly (continued)
Figure 3-42: Color Module Assembly (Part 1)
Refer to Figure 3-43 on
page 94 for this portion of
the assembly.
Refer to Figure 3-44 on
page 95 for this portion of
the assembly.
Dimmer
Strobe
Magenta
Cyan
Yellow
CTO
Fixed Colors
Driver PCBs
Blower
