VARI❋LITE - VL4000 BEAMWASH LUMINAIRE SERVICE MANUAL
136 02.9704.6010 0
Pan Module Assembly (continued)
Figure 3-69: Pan Module Assembly
11 (x2)*
*APPLY BLUE LOCTITE TO THE THREADS OF ALL SCREWS PRIOR TO INSTALLATION.
12 (x4)*
9
3
2
5 (x6)
10 (x2)
8
4 (x2)*
7
1
13 (x2)
6 (x2)
