Xerox Phaser 3330 Service Manual

Troubleshooting
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
2-55
Tray 2 Empty
The paper has run out in Tray 2.
Applicable Error
• 07-210: Paper Empty at Tray 2
Initial Actions
• Load paper in Tray 2.
• If problem persists use the following procedure.
Troubleshooting Reference Table
Troubleshooting Procedure Table
Applicable Parts Wiring and Plug/Jack Map Reference
• Tray 2 Paper Empty Sensor, (PL 12.4.5,
Parts List 12.4 Optional Tray Feeder Pick
Up Unit Assy).
• Main PWB: Phaser 3330 (PL 1.0.7, Parts
List 1.0 Phaser 3330 Main), WorkCentre
3335 and 3345 (PL 6.1.7, Parts List 6.1
WorkCentre 3335/3345 Main).
• Phaser 3330 Main PWB Connector Designators
• Phaser 3330 Control Panel PWB
• Wiring Diagrams for P3330/WC3335/WC3345
• WorkCentre 3335/3345 Main PWB Connector Designators
•DADF PWB
•SMPS PWB
Step Actions and Questions Yes No
1. Enter dC330 Component Control, code
07-210 to check the Tray 2 Paper Empty
Sensor and Paper Empty Actuator.
The display changes when the sensor is
actuated?
Go to step 4. Go to step 2.
2. Check that the sensor and actuator are
correctly installed and undamaged.
The sensor and actuator are good?
Go to step 3. Go to step 3.
3. Install a new Tray 2 Paper Empty Sensor (PL
12.4.5, Parts List 12.4 Optional Tray Feeder
Pick Up Unit Assy).
If necessary, install a new Tray 2 Empty
Actuator (CSP-SCF Actuator Feed),
(PL 12.4. 13, Parts List 12.4 Optional Tray
Feeder Pick Up Unit Assy).
Does the error persist?
Go to step 3. Complete.
