Xerox Phaser 3330 Service Manual

Troubleshooting
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
2-59
Output Bin Full
The Output Bin Full Sensor detected that the tray is 90% full.
Applicable Error
• 08-700: Output Bin full
Initial Actions
• Clear the output bin of paper.
• If problem persists use the following procedure.
Troubleshooting Reference Table
Troubleshooting Procedure Table
Applicable Parts Wiring and Plug/Jack Map Reference
• Out-bin Full Sensor (PL 3.1.20, Parts List
3.1 Frame (1 of 2))
• Main PWB: Phaser 3330 (PL 1.0.7, Parts
List 1.0 Phaser 3330 Main), WorkCentre
3335 and 3345 (PL 6.1.7, Parts List 6.1
WorkCentre 3335/3345 Main).
• Phaser 3330 Main PWB Connector Designators
• Phaser 3330 Control Panel PWB
• Wiring Diagrams for P3330/WC3335/WC3345
• WorkCentre 3335/3345 Main PWB Connector Designators
•DADF PWB
•SMPS PWB
Step Actions and Questions Yes No
1. Enter dC330 Component Control, code
08-720 to check the Out-bin Full Sensor.
The display changes when the sensor is
actuated?
Go to step 3. Replace the Out-bin Full
Sensor (PL 3.1.20, Parts
List 3.1 Frame (1 of 2))
Note: Refer to the sensor
actuator to identify the
specific sensor.
• 3330 Out-bin Full
Actuator (PL 1.1.9,
Parts List 1.1 Phaser
3330 Top Cover)
• 3335/3345 Out-bin
Full Actuator (PL
6.2.6, Parts List 6.2
WorkCentre
3335/3345 Middle
Cover)
Continue with step 2.
2. Re-seat CN2 on the Main PWB.
Does the error persist?
Go to step 3. Complete.

Xerox Phaser 3330 Specifications

General

Print Technology	Laser
Print Speed	Up to 42 ppm
Print Resolution	Up to 1200 x 1200 dpi
First Page Out Time	As fast as 6.5 seconds
Monthly Duty Cycle	Up to 80, 000 pages
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	850 sheets
Processor Speed	600 MHz
Memory	256 MB
Paper Output Capacity	150 sheets
Print Languages	PCL 5e, PCL 6, PostScript 3
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	Letter, Legal, Executive, A4, A5
Maximum Paper Size	8.5 x 14 in (Legal)
Weight	10.6 kg
