Xerox Phaser 3330 Service Manual

General Information
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
1-39
Printing Specifications
Output Stacking
Capacity Face-Down
150 sheets @80 g/m
2
150 sheets @80 g/m
2
Face-Up 1 sheet 1 sheet
Output Full Sensing Yes Yes
Automatic Duplex
Supporting Built-in Built-in
Media Sizes A4, Letter, Oficio, Folio, Legal A4, Letter, Oficio, Folio, Legal
Media Types Plain Paper, Thin, Thick, Recycled,
Bond, Cardstock, Archive
Plain Paper, Thin, Thick, Recycled,
Bond, Cardstock, Archive
Media Weight
16~32 lb. (60 to 120 g/m
2
) 16~32 lb. (60 to 120 g/m
2
)
ADF/DADF
Capacity
N/A
50 sheets @80 g/m
2
2-sided Document Scanning N/A WorkCentre 3325 only
Paper Size
N/A Width: 142~216mm (5.6"~8.5")
Length: 148~356mm (5.8"~14.0")
Paper Weight
N/A WorkCentre 3315: 16~28 lbs.
WorkCentre 3325: 12.5~28 lb.
Feeding Order
N/A Top to bottom feed
Characteristic Specification
Printing Technology Recording System: Laser electro-photographic system using OPC Drum and direct
transfer to the media.
Exposure System: Laser printhead
Transfer System: Finished image is transferred onto the media
Fusing System: Thermal fusing system by belt
Color Medium Black Toner Cartridge
Print-Quality Mode Standard 600 x 600
Enhanced 1200 x 1200
Non-printable Area Envelope 10 mm (0.4”) from edge (top, bottom, left, and right)
Other Media 4 mm (.16”) from edge (top, bottom, left, and right)
Printer Life Phaser 3330DN
Phaser 3330DNM
WorkCentre 3335
WorkCentre 3345
170,000 pages or 5 years (whichever comes first)
220,000 pages or 5 years (whichever comes first)
170,000 pages or 5 years (whichever comes first)
220,000 pages or 5 years (whichever comes first)
Warm-Up Time
From Sleep Mode
Phaser 3330DN
Phaser 3330DNM
WorkCentre 3335
WorkCentre 3345
35 seconds
35 seconds
As fast as 35 seconds
As fast as 35 seconds
Item Phaser 3330 WorkCentre 3335/3345
