Xerox Phaser 3330 Service Manual

Parts Lists
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
5-3
Using the Parts List
• ID No.: The callout number from the exploded part diagram.
• Name/Description: The name of the part to be ordered and the number of parts supplied per
order.
• Part Number: The material part number used to order that specific part.
• Parts identified throughout this manual are referenced PL#.#.#; For example, PL3.1.10 means the
part is item 10 of Parts List 3.1.
• A Black triangle preceding a number followed by a parenthetical statement in an illustrated parts
list means the item is a parent assembly, made up of the individual parts called out in
parentheses.
•The notation “with X~Y” following a part name indicates an assembly that is made up of
components X through Y. For example, “1 (with 2~4)” means part 1 consists of part 2, part 3, and
part 4.
Note: Only parts with part numbers are available for ordering. Parts without part numbers are
available on the parent assembly.
WorkCentre 3335DNM, 110V Engine 5BT 700000 5BT 709999
WorkCentre 3335DNM, 220V Engine 338 710000x 338 721999x
WorkCentre 3335DN, 110V Engine 5BT 722000 5BT 739999
WrokCentre 3335DN, 220V Engine 338 740000x 338 799999x
WorkCentre 3345DNM, 110V Engine 3BT 800000 3BT 814999
WorkCentre 3345DNM, 220V Engine 338 815000x 338 832999x
WorkCentre 3345DN, 110V Engine 3BT 833000 3BT 862999
WorkCentre 3345DN, 220V Engine 338 863000x 338 947999x
Product Starting Serial Number Ending Serial Number
