Xerox Phaser 3330 Service Manual

Troubleshooting
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
2-57
Bypass Empty
The Bypass Tray is empty.
Applicable Error
• 07-500: Paper Empty at Bypass Tray
Initial Actions
• Load originals in the Bypass Tray.
• If problem persists use the following procedure.
Troubleshooting Reference Table
Troubleshooting Procedure Table
Applicable Parts Wiring and Plug/Jack Map Reference
• Bypass Paper Empty Sensor, (PL 3.2.10,
Parts List 3.2 Bypass Tray)
• Main PWB: Phaser 3330 (PL 1.0.7, Parts
List 1.0 Phaser 3330 Main), WorkCentre
3335 and 3345 (PL 6.1.7, Parts List 6.1
WorkCentre 3335/3345 Main).
• Phaser 3330 Main PWB Connector Designators
• Phaser 3330 Control Panel PWB
• Wiring Diagrams for P3330/WC3335/WC3345
• WorkCentre 3335/3345 Main PWB Connector Designators
•DADF PWB
•SMPS PWB
Step Actions and Questions Yes No
1. Enter dC330 Component Control, code
07-510 to check the Bypass Paper Empty
Sensor and Empty MP Actuator.
The display changes when the sensor is
actuated?
Go to step 4. Go to step 2.
2. Check that the sensor and actuator are
correctly installed and undamaged.
The sensor and actuator are good?
Go to step 3. Go to step 3.
3. Install a new Tray 2 Paper Empty Sensor (PL
12.4.5, Parts List 12.4 Optional Tray Feeder
Pick Up Unit Assy).
If necessary, install a new Empty MP
Actuator ,(PL 3.2.8, Parts List 3.2 Bypass
Tray).
Does the error persist?
Go to step 3. Complete.
