Service Parts Disassembly
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
4-37
5. Disconnect the boss on the shaft holder and rotate it upward.
6. Disconnect the spring.
s3320-070
Tab
Catch on the
underside
s3320-072
Spring
