Xerox Phaser 3330 Service Manual

Service Parts Disassembly
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
4-77
8. Disconnect the Modem Interface Cable at P/J1 on the Fax Board.
9. Remove the Upper Middle Cover (page 4-23).
10. Disconnect the Modem Interface Cable at P/J1 and the speaker cable at P/J2.
11. Remove 3 screws (silver, flanged, tapping, 10 mm) and remove the Fax Board.
SCREWS (3)
P/J 1
