Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345

Service Manual

5-21

Parts List 3.3 Fuser

Item Name Part Number

1 F/UP Idle Shaft IEX -

2 NTC Assy Thermistor 130N01668

3Thermostat -

4 Halogen Lamp (110V/220V) -

5R Lamp Cap -

6ETC Spring -

7CS Spring -

8CS Spring -

9ETC Spring -

10 ETC Spring -

11 Ball Bearing -

12 Joint Fuser Harness -

Con Fuser Harness

14 PR 1st Bush -

15 Claw Guide -

16 Ground PR Guide -

17 Jam Holder -

18 Fuser Frame -

19 HR Bush -

20 2nd PR Bush -

21 Input Guide -

22 Bearing Bracket -

23 Gear Bracket -

24 PR M Ground -

25 Fuser Cover -

26 Idle Roller -

27 Pressure Roller -

28 2nd Pressure Roller -

29 Fuser Gear -

30 Exit Idle Gear -

31 L Jam Link Lever -

32 R Jam Link Lever -

33 Exit Idle Roller -

34 Heat Roller -

35 L Lamp Cap -

36 Fuser (110V)

Fuser (220V)

126N00410

126N00411
