Parts Lists

Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345

Service Manual

5-25

Parts List 3.5 Drive

Item Name Part Number

1 BLDC Motor (Main Drive Motor) 127N07912

2Motor Bracket -

3 95-81 Exit Gear -

4 65-28 Feed Gear 022N02857

5 79 IN DR Fuser Gear -

6 59 Idle Gear -

7 73 Coupler Gear -

8 53 Out DR OPC Gear -

9 73 Idle Gear -

10 Clutch Hub -

11 CS Spring -

12 Coupler -

13 69 IN DR OPC Gear -

14 Cam Coupler -

15 29 DR Fuser Gear -

16 Gear Bracket -

17 Clutch Hub Gear -

18 Drive 007N01826
