Xerox Phaser 3330

Parts Lists
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
5-31
Parts List 5.1 Tray 1
Item Name Part Number
1 Cassette Cover Handle -
2 Cassette Frame Assembly -
3 Cassette Handle -
4Paper Indicator -
5 Right Cassette Guide -
6 Rear Guide Cassette -
7 Retard Roller Cassette -
8 Cassette Pad RPR (Base Plate Pad) 050N00646
9Pinion Gear -
10 Locker Plate -
11 Cassette Locker -
12 Cassette Ground -
13 Cassette Cover -
14 Knock Up Plate P -
15 Cassette Frame -
16 Left Guide Cassette -
17 Retard Shaft Holder -
18 CS Spring -
19 Tray 1 Cassette Assembly 050N00694
