Xerox Phaser 3330 Service Manual

Parts Lists
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
5-33
PL 6.1 WorkCentre 3335/3345 Main
Note: All Main PWB spare parts are configured with a SOLD service plan. Any device with a
METERED billing plan will require a Plan Conversion Code to be entered to re-enable metered
support. Failure to do this may result in Invalid Toner Messages. Always follow all steps outlined in
the Main PWB replacement procedure.
Item Name Part Number
1
Front Cover Assembly (REF: PL 1.3)
002N03326
2 Tray 1 (REF:PL 5.1) 050N00694
3 Right Cover (REF:PL.1.2) 002N03333
4 Main Frame (REF: PL 3.1) -
5 Left Cover 002N03332
6 SMPS (110V) 105N02330
SMPS (220V) 105N02331
7 Main PWB (3335) (See Note) 140N63797
Main PWB (3345) (See Note) 140N63798
8 Duplex Assembly (REF: PL 4.1) 022N02856
9 Fuser (110V) (REF: PL 3.3) 126N00410
Fuser (220V) (REF: PL 3.3) 126N00411
10 Rear Frame (REF: PL 3.4) 001N00534
11 Rear Door 095N00415
12 LSU (Laser Unit) 130N01853
13 Lower Middle Cover 002N03336
14 Upper Middle Cover -
15 Control Panel Assy Refer to Parts List 10.1 WorkCentre
3335/3345 Control Panel (PL
10.1.22)
16
WorkCentre 3335 ADF (REF: PL 7.1)
-
16A
WorkCentre 3345 DADF (REF: PL 8.1)
-
17 Wireless Board 140N63805
18 SD Card 091N80340
19 Surge Protector (South Africa Only) 005N01172
20 Flat Cable (Modem Cable) 117N02065
