Parts Lists
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
5-37
Parts List 7.1 WorkCentre 3335 SCANNER and ADF
Item Name Part Number
1 ADF (REF:PL 7.3) 022N02859
2 Hinge 003N01117
3 Connector Cover -
4 Lower ADF Platen 090N00187
5 Platen (REF: PL.9.2) 090N00186
6Screw -
7 White Sheet 055N00320
8 ADF PWB 140N63806
