Xerox Phaser 3330 Service Manual

Parts Lists
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
5-39
Parts List 7.1A WorkCentre 3335 ADF (2/2)
Item Name Part Number
1 ADF 022N02859
2Screw -
3 Rubber Pad 108R01472
4Drive Gear -
5 White Bar 025N00104
6Roller -
7Paper Stopper -
8Idle Gear -
9 Gear Separate Roller -
10 Roller Pickup 130N01673
11 Pick up Housing 130N01854
12 Housing Pickup Assembly -
13 Sensor Harness -
14 Antistatic Brush -
15 Motor Bracket -
16 ADF Motor 127N07781
17 Front Edge Guide -
18 Rear Edge Guide -
19 Stacker -
20 Rear ADF Cover -
21 Front ADF Cover -
22 Cover Platen -
23 Slide Stopper -
24 Position Paper Actuator -

Xerox Phaser 3330 Specifications

General

Print Technology	Laser
Print Speed	Up to 42 ppm
Print Resolution	Up to 1200 x 1200 dpi
First Page Out Time	As fast as 6.5 seconds
Monthly Duty Cycle	Up to 80, 000 pages
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	850 sheets
Processor Speed	600 MHz
Memory	256 MB
Paper Output Capacity	150 sheets
Print Languages	PCL 5e, PCL 6, PostScript 3
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	Letter, Legal, Executive, A4, A5
Maximum Paper Size	8.5 x 14 in (Legal)
Weight	10.6 kg
