Parts Lists
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
5-41
Parts List 8.1 WorkCentre 3345 SCANNER and DADF
Item Name Part Number
1 DADF (REF:PL 8.1A) 022N02860
2 Platen/Scanner 090N00189
3Scan Cover -
4 Connector Cover -
5 White Sheet 019N00810
6 Lower DADF Platen 090N00188
7Screw -
8DADF PWB -
