Xerox Phaser 3330 Service Manual

Parts Lists
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
5-43
Parts List 8.1A WorkCentre 3345 DADF
Item Name Part Number
1 DADF Top Cover 002N03327
2Upper DADF (REF:PL 8.3) -
3 DADF Drive (REF:PL 8.5) 007N01829
4Lower DADF (REF:PL 8.2) -
5Platen DADF -
6DADF Front Cover -
7 DADF Hinge R 003N01145
8 DADF Hinge L 003N01146
9DADF Stacker -
10 DADF Rear Cover -
11 Slide Stopper -
12 DADF Harness -
13 DADF Board 140N63807
14 Zener GND CBF Harness -
15 Open Cover -
16 DADF Up Pick MEA Unit 130N01855
17 Stopper MEA Unit -
18 Sensor M DOC Guide -
19 Lifting Solenoid 121N01160
20 DADF 022N02860

Xerox Phaser 3330 Specifications

General

Print Technology	Laser
Print Speed	Up to 42 ppm
Print Resolution	Up to 1200 x 1200 dpi
First Page Out Time	As fast as 6.5 seconds
Monthly Duty Cycle	Up to 80, 000 pages
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	850 sheets
Processor Speed	600 MHz
Memory	256 MB
Paper Output Capacity	150 sheets
Print Languages	PCL 5e, PCL 6, PostScript 3
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	Letter, Legal, Executive, A4, A5
Maximum Paper Size	8.5 x 14 in (Legal)
Weight	10.6 kg
