Xerox Phaser 3330 Service Manual

Parts Lists
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
5-51
Parts List 9.2 WorkCentre 3335/3345 Platen
Item Name Part Number
1Upper Platen -
2CVT Glass -
3Scan Bracket -
4Upper Platen Ground -
5Platen Glass -
6Upper Scan Cover -
7Middle Platen -
8 Lower Scan Frame -
9Rear CIS Guide -
10 Image Sensor 130N01679
11 CIS Bracket -
12 Carriage Home Sensor 130N01574
13 Gear Timing Belt 007N01704
14 Scan Motor 007N01828
15 Front CIS Guide -

Xerox Phaser 3330 Specifications

General

Print Technology	Laser
Print Speed	Up to 42 ppm
Print Resolution	Up to 1200 x 1200 dpi
First Page Out Time	As fast as 6.5 seconds
Monthly Duty Cycle	Up to 80, 000 pages
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	850 sheets
Processor Speed	600 MHz
Memory	256 MB
Paper Output Capacity	150 sheets
Print Languages	PCL 5e, PCL 6, PostScript 3
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	Letter, Legal, Executive, A4, A5
Maximum Paper Size	8.5 x 14 in (Legal)
Weight	10.6 kg
