Xerox Phaser 3330

Troubleshooting
Phaser 3330 and WorkCentre 3335/3345 Xerox Internal Use Only
Service Manual
2-12
Service
Information
(con’t)
dc135 HFSI (con’t) Bypass Rubber Pad Life Page
Supplies Report...
Copier
Diagnostics
dC131 NVM Read/Write
dc132 NVM Initialization Initilize All NVM
dc305 UI Test UI Touch Screen Test
Display Pixel Test
LED Indicator Test
UI Panel Button Test
Au d io To n es Te st
Video Memory Test
Application Checksum Verification
dc330 Component Control 04-100 Main BLDC Motor
04-110 Main BDLC Motor Ready
04-200 Exit Motor Forward Fast
04-210 Exit Motor Forward Slow
04-220 Exit Motor Reverse
04-230 Duplex Motor Forward
04-310 Duplex Motor Backward
04-400 Duplex Fan Run
04-410 Duplex Fan1 Run Ready
04-420 Duplex Fan2 Run Ready
04-120 Main Fan
04-510 T1 Elevating Motor
04-520 T2 Elevating Motor
04-530 T3 Elevating Motor
04-540 T4 Elevating Motor
09-500 SMPS Fan Run
LEVEL 1 LEVEL 2 LEVEL 3
