Xerox Phaser 3330 Service Manual

Troubleshooting
Phaser 3330 and WorkCentre 3335/3345 Xerox Internal Use Only
Service Manual
2-16
Copier
Diagnostics
(con’t)
dc330 Component Control
(con’t)
12-810 Paddle Home Sensor
12-815 Front Jog Home Sensor
12-820 Rear Jog Home Sensor
12-825 Support Finger Home Sensor
12-830 Ejector Home Sensor
12-840 Stacker Top Sensor
12-845 Stacker Bottom Switch
12-850 Staple Home Sensor
12-855 Staple Ready Sensor
12-860 Low Staple Sensor
12-865 Paper Detector Sensor
12-870 Finisher Door Switch
12-875 IOT Set Sensor
12-880 Duplex Paper Sensor
05-100 DADF Doc. Detect Sensor
05-120 DADF Paper Length Sensor
05-130 DADF Registration Sensor
05-140 DADF Scan Sensor
05-160 DADF Door Open Sensor
05-200 DADF SCan Motor Forward
05-201 DADF Scan Motor Reverse
20-012 Sngl Tone 1 100Hz Ln1
dc612 Print Test Pattern
Format Hard Drive
Memory Clear
Shading Test
Serial Number Reset
Fax & NW
Diagnostics
dc131 NVM Read/Write-Fax
dc132 NVM Initialization-Fax
