Troubleshooting
Phaser 3330 and WorkCentre 3335/3345 Xerox Internal Use Only
Service Manual
2-36
ADF/DADF Jam
Paper jam occurred in the DADF.
Applicable Errors
• 05-100: DADF Jam1
• 05-300: DADF Jam3
• 05-400: DADF Jam4
• 05-700: DADF Jam7
• 05-900: DADF Jam0
Initial Actions
• Open the ADF/DADF Cover and remove all originals from the document feeder.
• Turn the machine off and then on, if the error persists use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map Reference
• DADF Pick Up Unit (PL 8.1A .16, Parts List
8.1A WorkCentre 3345 DADF)
• ADF Pick Up Assembly (PL 7.1.9 and PL
.7.1.10, Parts List 7.1 WorkCentre 3335
SCANNER and ADF)
•ADF Paper Path Assembly, (ADF Paper
Path Assembly (WorkCentre 3335))
• DADF Feed Roller (PL 8.2.14, Parts List
8.2 WorkCentre 3345 Lower DADF)
• DADF Rubber Unit (PL 8.2.14, Parts List
8.2 WorkCentre 3345 Lower DADF)
• DADF Lifting Solenoid (PL 8.18, Parts List
8.1 WorkCentre 3345 SCANNER and
DADF).
• DADF Feed Sensor (PL 8.2.24, Parts List
8.2 WorkCentre 3345 Lower DADF)
• DADF Registration Sensor (PL 8.2.13,
Parts List 8.2 WorkCentre 3345 Lower
DADF)
• DADF Drive (PL 8.5.8, Parts List 8.5
WorkCentre 3345 Drive DADF)
• ADF Motor (PL 7.1A.16, Parts List 7.1A
WorkCentre 3335 ADF)
• DADF Assembly (PL 8.1A.1, Parts List
8.1A WorkCentre 3345 DADF)
• ADF Assembly (PL 7.1A.1, Parts List 7.1A
WorkCentre 3335 ADF)
• Phaser 3330 Main PWB Connector Designators
• Phaser 3330 Control Panel PWB
• Wiring Diagrams for P3330/WC3335/WC3345
• WorkCentre 3335/3345 Main PWB Connector Designators
•DADF PWB
•SMPS PWB
To Next Page
