SPEC
4
ELECTRICAL SPECIFICATIONS
Item Standard Limit
Front suspension
Spring
Free length 248.8 mm (9.80 in) 243.8 mm
(9.60 in)
Installed length 244.3 mm (9.62 in) •
• •
Spring rate (K1) 8.8 N / mm (0.90 kg / mm, 50.22 lb / in) •
• •
Spring stroke (K1) 0 ~ 120 mm (0 ~ 4.7244 in) •
• •
Inner tube outer diameter 41 mm (1.61 in) •
• •
Fork oil
Quantity (each front fork leg) 0.475 L (0.418 lmp qt, 0.502 US qt) •
• •
Level (from the top of the outer tube,
with the outer tube fully compressed,
and without the fork spring)
92 mm (3.62 in) •
• •
Spring preload adjusting positions
Minimum 8 •
• •
Standard 7 •
• •
Maximum 0 •
• •
Rebound damping adjusting positions
Minimum* 10 •
• •
Standard* 6 •
• •
Maximum* 1 •
• •
Compression damping adjusting
positions
Minimum* 13 •
• •
Standard* 6 •
• •
Maximum* 1 •
• •
*from the fully turned-in position
Rear suspension
Spring
Free length 167.5 mm (6.59 in) •
• •
Installed length 157.5 mm (6.2 in) •
• •
Spring rate (K1) 103 N / mm (10.5 kg / mm, 587.83 lb / in) •
• •
Drive chain
Maximum 15-link section •
• • 239.3 mm
(9.42 in)
Item Standard Limit
Ignition system
CDI unit model (manufacturer) F8T828 (MITSUBISHI) •
• •
Fuses (amperage
× quantity)
Radiator fan motor fuse 15 A
× 2• • •
CHASSIS SPECIFICATIONS /
ELECTRICAL SPECIFICATIONS
